STORAGE GROUPS: Create, load and save your preset incl.

SW-P08) to the outside to be remote controlled by automation systems.

VIRTUAL LAYERS: Provides a crosspoint matrix via control protocol (e.g.

VIRTUAL SIGNALS: Creates „re-entries“ without using physical resources of a router.

META GADGETS: Allow to “link” any parameter to a source or destination for direct access.

GADGETS: Controls an unlimited amount of external device parameters.

GPI: Provides a powerful logic toolset to create custom workflows.

vsmTALLY: Generates Tally, combines it with external triggers and sends Tally to external consumers.

INTEGRATED FEATURES (Full Licence Version) With the use of VSM’s timers and routing management, operators and editors are supported significantly, so that they can concentrate on the creative part of the job. In daily operations, recurring studio swaps can be the normal and with VSM these automatic actions are easy to implement. With VSM, satellite downlinks and ISDN codecs can be implemented seamlessly and simply coordinate the original source and final destination. With the use of VSM’s tieline management functionalities even decentralized broadcast facilities are easy to control. Transmission line and audio source management is also easy to handle – with continuous signal flow control. The handy apology rules editor helps to manage even complex fall back and backup scenarios. A rule management system, that can be defined freely, assists in the automatic change of transmission lines, audio sources, peripheral equipment or can trigger emergency switchings. For instance, in combination with appropriate audio routers, silence detection is managed easily. The VSM system takes into account the unique requirements of a Radio MCR, thus providing special functions for radio applications. If one of the devices fails, VSM will automatically re-route the signal to another spare device without user intervention.Īlready installed in numerous MCRs across the world, VSM is your trusted partner to handle even the largest and most sophisticated system requirements.

EVERTZ LOGO INSERTER MANUAL FREE

With VSM’s unique “Pooling” function, customers can easily manage their signals through the whole MCR by automatically inserting free “pooled” devices dynamically and automatically setting the device so that the signal arrives in the right format. Signal path overviews and automatic handling of different signal types and formats are also essential requirements for a unified control system designed for this use. Quick operational reaction to failed devices is essential to ensure transmission lines never go “dead”.

InĪddition, control requirements are based around pre-programmed transmission switching, switching control from third-party automation systems, signal monitoring and alarms with automatic routing based on specific alarm status or logic detection.

EVERTZ LOGO INSERTER MANUAL TV

Additionally, a global naming facility for mixers, UMDs, user panels and many other devices provides status information at a glance.Īny system to be utilized in the mission-critical MCR application for TV must offer sophisticated redundancy features to ensure 24/7 operation without critical failures under any circumstances. This guarantees maximum transparency for every operator and every control unit.

All VSM user interfaces display the confirmed action from an attached device, for example, a router. As a unique feature, real time feedback from every single crosspoint and parameter is available, as well as special applications such as audio metering via the protocol. All the advantages of IP connectivity, such as its high data performance and standard management components, increase the power of a complete broadcast system. The IP infrastructure of a VSM network, including all control panels, interfaces and external devices, guarantees easy installation. User panels and interfaces can be configured without limitation to meet the requirements of different workflows and applications, while the whole system is under redundant control. The “everything under one roof” philosophy unites technical devices and operators in a most adaptable way. A VSM IP control system brings together all the requirements for a safe and flexible broadcast operation.
